HP Integrity rx6600 Service Manual

2 System Specifications
Server Specifications
Table 14 lists the server specifications.
Table 14 Server Specifications
SpecificationComponent
rx6600 with PCI/PCI-X/PCIe IOBPrx6600 with PCI/PCI-X IOBP
One, two, three, or four Itanium dual-core processors:Processors
• 1.4 GHz / 12 MB cache
• 1.6 GHz / 18 MB cache
• 1.6 GHz / 24 MB cache
24-DIMM memory carrier or 48-DIMM memory carrier
Supported DDR2 DIMM sizes:
Memory
• 512 MB
• 1 GB
• 2 GB
• 4 GB
• 8 GB
One to 16 hot-pluggable SAS hard drivesDisk drives
Two private PCI-X 66 MHz slotsPCI slots
Eight Public slots:Eight public PCI-X slots:
• Two PCI-X slots, 66 MHz• Four PCI-X slots, 66 MHz
• •Two PCI-X slots, 133 MHz Two PCI-X slots 133 MHz
•• Four PCIe, x8Two PCI-X2 slots, 266 MHz
SAS core I/O
options
• Eight port SAS core I/O card (PCI-X)• Eight port SAS core I/O card (PCI-X)
• •Eight port SAS core I/O card with RAID (PCI-X) Eight port SAS core I/O card with RAID (PCI-X)
• Eight port SAS core I/O card with RAID (PCIe)
• Eight port SAS core I/O card with RAID able to
connect to external storage (PCIe)
Two GigE LAN portsLAN core I/O
Two serial ports, two USB 2.0 ports, one 10 Base-T/100 Base-T LAN port, and one optional VGA portManagement
core I/O
One DVD or DVD+RW driveOptical
device
One 1600 watt power supply, 1+1 redundancy with second power supplyPower supply
Dimensions and Weight
Table 15 lists the dimensions and weight of the server for a rack- or pedestal-installed configuration
.
Server Specifications 39

HP Integrity rx6600 Specifications

General

Processor	Intel Itanium 2
Network	Integrated dual Gigabit Ethernet
Form Factor	5U rack-mountable
Power Supply	Redundant hot-plug power supplies
Processor Speed	1.6 GHz
Memory Type	DDR2 ECC Registered
RAID Support	Yes
Operating System	HP-UX, Linux, Windows Server
