The latest firmware, drivers, utilities, software, and documentation for HP Integrity servers are
available on the support page of the HP website at http://www.hp.com/support/itaniumservers.
Connecting External Storage
IMPORTANT: Not all OSs support external drives.
To connect external storage, follow these steps:
1. Power off the server.
2. Connect an external SAS cable to the external port of the controller.
NOTE: You do not have to disconnect any internal drives on shared internal port 1I because
the controller preferentially discovers devices attached to port 1E. However, drives on the
shared internal port are unavailable until you disconnect the external storage device.
3. Tighten the lock screws on the cable connector.
4. Attach the other end of the cable to the SAS input connector of the external storage enclosure.
IMPORTANT: Drives that are to be used in the same array must be of the same type, either
all SAS or all SATA. (Parallel SCSI drives cannot be used with this controller.)
5. Tighten the lock screws on the cable connector.
6. Power on the enclosure.
7. Power on the server.
SAS Cable Part Numbers
If you require additional cables, order them by the option kit number listed in Table 34.
Table 34 SAS Cable Part Numbers
Cable Assembly NumberOption Kit NumberCable Length
361317-001389664-B211.0 m (3.3 ft.)
361317-002389668-B212.0 m (6.6 ft.)
361317-004389671-B214.0 m (13 ft.)
361317-006389674-B216.0 m (20 ft.)
SAUPDATE Utility
Use saupdate from the EFI Shell to update the firmware image on the HP Smart Array Controller.
Command line options are described below. Follow one of these two procedures to run saupdate:.
• If you are using saupdate from the Offline Diagnostic CD:
1. Download the firmware and copy it to the EFI partition.
2. The CD containing saupdate.efi must be in the drive before booting the system to allow
device mapping.
3. Boot the system to the EFI Shell prompt. The CD drive should appear in the list of mapped
devices as fs0.
4. Change to this device by entering fs0: under the EFI Shell prompt.
5. If the EFI utility and firmware image files are not located in the root directory, move to the
directory in which these files are located, for example:
fs0:\>cd\EFI\HP\TOOLS\IO_CARDS\SmartArray
Core I/O Card Configuration 105
