92
8. Enter 0 to return to the Serial submenu.
===========================<Enter Serial SubMenu>===========================
|Note:the operating device is flash |
|<1> Download Image Program To SDRAM And Run |
|<2> Update Main Image File |
|<3> Update Backup Image File |
|<4> Download Files(*.*) |
|<5> Modify Serial Interface Parameter |
|<0> Exit To Main Menu |
===================================================================
=========
Enter your choice(0-4):
9. Select an option from options 2 to 3 to upgrade a system software image. For example, enter 2 to
upgrade the main system software image.
Please Start To Transfer File, Press <Ctrl+C> To Exit.
Waiting ...CCCCC
10. Select Transfer > Send File in the HyperTerminal window.
Figure 6 Transfer menu
11. In the dialog box that appears, click Browse to select the source file, and select Xmodem from
the Protocol list.
Figure 7 File transmission dialog box
12. Click Send. The following dialog box appears:
