CONCEPT 4000. User Manual.
THE PRISMA COLOUR GRAPHIC TERMINAL
Default LCD Display.
The Prisma Terminal offers a number of options for the Default display.
This is the display that will be shown when there are no User operations being
performed, and no Alarms or other messages to be displayed.
The Default display can be selected separately for each Terminal in your system.
The settings can only be programmed by the Installer, who can also advise you on the
appropriate options. If no specific Default Display option has been chosen, the
Concept 4000 logo will be displayed.
SINGLE AREA STATUS.
This option allows the name and current status of
a single Area to be displayed. This is useful when
the Terminal only provides control of one Area.
MULTIPLE AREA STATUS.
The Multiple Area status screen allows the
current status of 8 Areas to be viewed by name.
The icon against each Area name indicates the
current status; Off (Disarmed), On (Armed),
Timed Off (Defer Arming timer running) or Defer
Warning (Timer about to expire).
See “Turning Areas Off” for details of the Defer
Arming feature.
TIME & DATE. (V5 or later only)
Allows the current system Time & Date to be
displayed. This is useful in systems that generate
Time-On-Site reports, providing a display of the
actual system Date & Time being logged.
Time & Date display is at the bottom of the screen
if the Multiple Area Status option is selected.
Admin
Kitchen
Bistro
Public Bar
Bottle Shop
Cellar
Cool Room
Band Room
Menu Log On
Library
is Off
Menu Temp 25.3°C Log On
Monday, 18th Apr 11:25am
Library
is Off
See picture on p126 and refer to the Prisma Colour Graphic Terminal User Manual
for full details.
