CONCEPT 4000. User Manual.
View Area Status.
Individual LCD Terminals may be programmed to allow Users to view the current status
of Areas without needing to Log on to the Terminal. (V3 or later only)












If this option is enabled, simply press the <UP> or
<DOWN> arrow on the LCD Terminal.
Area Array Option.
If Area Array is enabled, the display will show the
first 8 Areas in the system, with a letter below each
to indicate the current Status. See table below.
The <UP> and <DOWN> arrow keys will step to
the previous 8 Areas or next 8 Areas respectively.
The number on the bottom left of the display
indicates the first Area shown in the current array.
e.g. 009 = Areas 9 to 16.
017 = Areas 17 to 24.
Etc.
Text Array Option.
If this option has been selected, the display will show
the status of the Area associated with the Terminal
in text form. See table below.
The <UP> and <DOWN> arrow keys will step to
the previous Area or next Area respectively.
This option can only be used to view the status of 8
Areas beginning at the Terminal’s associated Area.
Press <END> when finished.


















Array Text Description
Y is On Area is On.
n is Off Area is Off.
T is Timed Off Area is Off with a Defer timer running.
W About to turn On (Warning period) Area is Off with a Defer timer about to
expire and turn the Area On.
See “Turning Area/s OFF” for more information on Area Defer timers.
