CONCEPT 4000. User Manual.
LCD AND PRISMA COLOUR GRAPHIC TERMINALS
Many system operations, such as turning Areas ON and OFF, are usually performed
at a Terminal. A system may have up to 99 Terminals connected. Any of these
Terminals can be used to operate the system, however, the system may be
programmed to limit the operations available at some Terminals.
See pictures on p125 & 126. See “The LCD Terminal” on p8-11 and “The Prisma
Colour Graphic Terminal” on p12-13 for details of display and keypad functions.
USING A TERMINAL. The first step in using an LCD Terminal is to logon with
your secret PIN code using the digit keys, then the <OK> key. The system will
identify you and may greet you by name with a message on the display.
After a few seconds, the display will prompt you with the name of the first Area (or
Area List) that you are allowed to turn ON and/or OFF and the action required.
THE DISPLAY. The LCD display is used to annunciate alarms, show the status of
the system, and guide the User through operations and programming using plain
English text. Sometimes it is necessary for the message to be longer than the width
of the display. When this occurs, the message will automatically scroll slowly to the
left so that you can view the entire text.
Many items in the system can have names programmed to provide easy identification
via the LCD Display (e.g. Users, User Types, Areas, Zones, Home Auxiliaries, etc.)
If an item used in your system is only identified by the default name -
e.g.
(the item ID number, preceded by a full stop), you may wish to ask
the Installer or System Administrator to program a more suitable name for the item.
HELP. A special feature of this product is the <HELP> key. No matter what stage of
an operation you are up to, pressing the <HELP> key will display a Help message
related to the specific operation you are performing. If at any time you are not sure
what to do next when using the system, press the <HELP> key.
WEATHERPROOF TERMINALS
The Inner Range Weatherproof Terminal may be used to turn an Area ON and OFF
&/or unlock a Door. This unit has a keypad with digit keys (0-9), OK key, ON/OFF
key and a beeper. Two lamps are also provided:
- A Green “Code” lamp to indicate a User is logged-on
- A Red “Area status” lamp. NOTE: Only operates while a User is logged on.
- Older units may also have two general purpose Yellow lamps.
See picture on p126 and “Weatherproof Terminal Operations” in this manual.
TOUCHSCREEN TERMINALS
A Colour Touchscreen Terminal is also available that provides access to most of the
control and monitoring operations. See picture on p125.
Refer to the Touchscreen Terminal User Manual for details.
