CONCEPT 4000. User Manual.
VIEW INPUT STATES
The system can be programmed to allow Users to
view a summary of specific Zones that are enabled
and currently in an abnormal condition.
“INPUT STATES” can then be used to display the
summary. (V3 or later only)
You may need to use this function when the LCD
Terminal displays a message such as:
“Some Inputs are Tampered”
“Some Inputs are Isolated”
etc.
The display will show the first Zone that is in an
abnormal state.
The summary is prioritised in the following order:
1) Isolated Inputs
2) Tampered Inputs
3) Unsealed Inputs
The <DOWN> arrow key can be used to scroll
through the list of other abnormal Zone states.
When the bottom of the list is reached, the display
will show “Finished Check” to indicate that there
are no more abnormal Zones to view.
Press the <END> key to exit to the normal
display.


















REMEMBER !! Any time you need it,
is as close as the press of a key.
IMPORTANT NOTE: This
operation is replaced by the
“Clear Trouble Zones”
operation in some European
countries (e.g. UK).
See next page for details.
