CONCEPT 4000. User Manual.
Access a Floor in an Elevator.
After presentation of the Card, the LCD Terminal
will display a prompt for the PIN code.
Enter your PIN code followed by the <OK> key.
The LCD will then return to the normal display and
you can proceed to select a Floor.






Using a Card Reader.
In Lift Access Control systems, Floors are commonly accessed using Card Readers in
conjunction with the Floor Selection buttons with the following procedure:
1) In most cases the Card, Key fob or Insert key (etc) is simply swiped or presented
to the Reader inside the Lift Car, in the required manner.
The system may be configured so that the Reader LED/s and/or beeper provide
an indication of Valid or Invalid Card. (Consult the Installer for details)
2) The User then selects the Floor they wish to go to. Note that the User has a
limited time (typically 5 to 10 seconds) to select the Floor and only one Floor
should be selected for each Card presented.
3) The system then checks the User’s credentials and the Floor button lamp
illuminates in the normal manner if the selected Floor is allowed.
4) Details of the action are recorded in Review.
e.g. Jane Wills Card access at Lift Car 003.
Bob White denied at Lift Car 4 - Not in List.
Card + PIN: In some applications, presentation of the Card must be followed by entering
your PIN code at an associated LCD Terminal before a Floor can be selected.
- ,
