“No incoming data. Please check synchronization mode …”
If SESWIN gets no data from the system, there is a timeout after some time and this message
shows up. Often this is due to synchronization is set to “external trigger” and no trigger pulse is
received.
Look at “System Setup – Settings – General – Synchronisation” and change the mode to
'Internal'. See also section 5.11.3 on page 60.
If you have to use “External Trigger”, make sure there is a synchronisation signal fed to the
“Sync IN” input. The synchronisation modes and the necessary trigger signal are described
in section 6 on page 81.
“xxx Transducer is not plugged. Abort action …”
“Sub-bottom Transducers and/or Junction Box not plugged. Abort action …”
“Junction Box not plugged. Abort action …”
Every time the transmitters are switched on, the system checks if the transducer cables are
plugged in. If no transducer is plugged, the transmitters are not switched on.
Check if the transducer is connected properly. Unplug and plug again.
This message might be also shown if there is some data/communication problem between
SESWIN and the internal controller, in this case the echo print screen is not scrolling from
left to right.
“xxx Transducer is not plugged. Continue?”
Every time the transmitters are switched on, the system checks if the transducer cables are
plugged in. For some models and system variants with more than one transducer cable it is
possible to operate the system at reduced performance with just a part of the transducer. This
message shows up to remind you that not all the cables are plugged and thus the system will not
operate at full power.
“Reset on Control port detected. Transducer switched off.”
If the internal firmware controller is reset, SESWIN shows this message. This might happen if the
controller crashes due to faulty parameters that were not detected by the built-in parameter
check. Please check the range settings and the transducer depth.
“Recording ERROR SES-File”, “Recording ERROR RAW-File”,
“Record Folder is not allowed or missing. Please select a different.”
This message shows up, if the data cannot be logged on the specified drive/folder. Please check
the settings in “System Setup – Settings – General – Files”, see also section 5.11.4 on page 61.
The current folder does either not exist or you have no permission to create and change files in
this folder. Make sure to set the “Record Folder” to a folder on the internal local hard disk. USB
or network drives should not be used.
“Backup Path not found. Disabled function ...”
This indicates that the data backup folder specified was not found while doing the backup. The
data backup function will be disabled, the data logging is still operational. Please check the
settings in “System Setup – Settings – General – Files” and if the destination folder is accessible.
See also section 5.11.4 on page 61. The current folder does either not exist or you have no
permission to create and change files in this folder.
