User’s Manual INNOMAR Parametric Sub-Bottom Profilers / SESWIN 13
Innomar Technologie GmbH (2023-01) 13
1 Important Hints – Attention Please!
1.1 Safety Rules
For the user's safety and the safety of any person nearby the INNOMAR SBP systems and for the
non-damageable operation of the system it is strictly pointed out that:
THE INNOMAR DEVICE MUST BE OPENED BY AUTHORIZED STAFF ONLY
CABLES MUST BE CONNECTED OR DISCONNECTED ONLY WHEN THE POWER IS
SWITCHED OFF; ESPECIALLY THE TRANSDUCER CABLE
THE EQUIPMENT MUST BE USED ONLY IF THE TRANSDUCER IS CONNECTED AND IS
SITUATED IN WATER
IT IS FORBIDDEN TO SWIM OR DIVE WHILE THE INNOMAR SYSTEM IS WORKING
THE INNOMAR TOPSIDE ELECTRONICS IS NOT WATERPROOF AND HAS TO BE USED
IN A DRY AND WATER PROTECTED ENVIRONMENT
ALLOW FREE ACCESS OF AIR TO THE COOLING SLOTS (FRONT, REAR, BOTTOM) TO
AVOID OVERHEATING
THE INNOMAR DEVICE IS A SENSITIVE INSTRUMENT AND SHOULD BE HANDLED
CAREFULLY
THE TRANSDUCER’S ACTIVE AREA HAS TO BE PROTECTED AGAINST MECHANICAL
DAMAGES, PRESSURE, CHEMICALS AND SUNLIGHT
DO NOT CHANGE THE SETUP OF THE SYSTEM'S OPERATING SYSTEM OR CONTROL-
PC’S BIOS
DO NOT INSTALL ANY OTHER SOFTWARE OR DEVICE DRIVER ON THE CONTROL
COMPUTER
UNUSED TOPSIDE UNITS SHOULD BE POWERED UP AT LEAST EVERY SIX MONTHS
TO AVOID DAMAGES ON ELECTRONIC COMPONENTS
INNOMAR is not liable for any damages that result from disregard these safety rules or any other
improper operation of the INNOMAR SBP systems.
1.2 Innomar SBP User Manual
This manual describes how to install and use the INNOMAR sub-bottom profilers and is applicable
to all INNOMAR SBP models.
The manual is divided into a “QuickStart Manual” (chapter 2, page 17), a hardware orientated
part (chapter 3, page 25) and a description of the INNOMAR control and data acquisition software
SESWIN (chapters 4 to 8). First the SESWIN software is explained item by item (chapter 5), then
use cases are discussed (chapters 6 and 7). For questions and trouble-shooting, please refer to
chapters 8 and 13.
Italics is used for file and path names.
Keys belonging to the keyboard are enclosed in brackets. If some keys have to be
pressed at the same time, they are separated by ‘+’ (example: [Ctrl]+[Alt]+[Del]).
The symbol marks a very useful hint or key fact.
The “Quick Start Manual” (page 17) summarizes how to get good results. It might be a
good idea to have these pages at hand during installation and operation of the INNOMAR
sub-bottom profiler. Checklists are also given in Appendix A.20 on page 219.
