A.13 Innomar quattro / sixpack Multi-Transducer SBPs
The INNOMAR quattro and sixpack models are parametric narrow-beam sub-bottom profiler (SBP)
with four/six transducers and echo sounder functionality. The main application is to acquire sub-
bottom data at high resolution in extremely shallow waters at high sounding density and to
produce three-dimensional visualization of these data sets. In deeper waters the transducers can
be combined to provide better range and/or penetration capability.
Main Technical Specifications
Primary High Frequencies (PHF) approx. 100 kHz (band 85 – 115kHz)
Primary Source Level >235 dB//µPa re 1m (single transducer; QBM/HBM)
>240 dB//µPa re 1m (2 transducers combined; DBM/TBM/PBM)
>245 dB//µPa re 1m (4 transducers square matrix, SBM)
>248 dB//µPa re 1m (6 transducers matrix, SBM)
Secondary Low Frequency (SLF) 4, 5, 6, 8, 10, 12, 15 kHz (centre frequency, user selectable)
SLF Total Frequency Band 2 – 22 kHz
SLF Pulse Type / Width Ricker, CW / 0.07 – 1 ms (user selectable)
Beam Width (-3dB) about ±2.5° (single transducer) for all frequencies
about ±1.5° (four-transducer 2×2matrix) for all frequencies
Heave / Roll / Pitch compensation yes / yes / yes (roll/pitch values applied for 3D rendering only);
there is no active beamforming during transmitting and receiving
Water Depth Range 0.5 – 100 m (single transducer; QBM/HBM; for 3D data sets the
water depth should not exceed 30 meters)
1 – 500 m (two-transducer 1×2 matrix, DBM/TBM/PBM)
1 – 1,000 m (four-transducer 2×2 square matrix, SBM)
1 – 1,500 m (six-transducer 2×3 matrix, SBM)
Sediment Penetration up to 20m (single transducer)
up to 50 m (four-transducer 2×2 square matrix)
up to 70 m (six-transducer 2×3 matrix)
Sample Resolution / Range Resolution <1 cm / up to 5 cm (depending on pulse settings)
Pulse Rate up to 60 pings/s
Data Acquisition and Recording digital 24 bit / 96 kHz; full waveform (“SES3” file format)
External Sensor Interfaces HRP (motion), GNSS position, depth (all RS232 / UDP), trigger
Bottom Detection internal (HF and LF data) or external depth
Depth Accuracy (3 cm @ 100 kHz / 6 cm @ 10 kHz) + 0.1% of water depth;
Remote Control / Survey Integration KVM / basic functions via COM or Ethernet (UDP), NMEA
Transceiver Dimensions / Weight “quattro”: 52 cm × 40 cm × 34 cm (19’’ / 7U) / c. 32 kg
“sixpack”: 52 cm × 40 cm × 34 cm (19’’ / 7U) / c. 34 kg
Transducer Dimensions / Weight 21 cm × 21 cm × 8 cm / c. 5 kg (single transducer, excl. cables)
Survey Vessel Speed up to 15 knots (depending on survey goal, weather conditions)
Power Supply 100 – 240 V AC / 50 – 60 Hz (fuse 16 A / slow)
Power Consumption “quattro”: <300 W
“sixpack”: <350W
(max. power-on inrush current 25 A / <100 ms)
Environmental Conditions Storage: -10…+60°C / <90% non-condensing rel. humidity
Operation: 0…+40°C / <70% non-condensing rel. Humidity
Control & Data Acquisition PC Integrated PC (MS Windows
®
10/11 OS) with 10’’ TFT display
Min. Specs: proc. I5, 8 GB RAM, 1 TB SSD, Geforce GT710 1
GB graphics card, 1 Gbit Ethernet, connections to auxiliary
sensors
First / Latest Product Generation 20015 / 2021
Technical specs are subject to change without prior notice, see www.innomar.com/products for latest infos.
