15-4 SCPI Reference Tables Model 2700 Multimeter/Switch System User’s Manual
CALCulate3 Subsystem to control CALC 3 (limit test): Sec 9
:MLIMit Path for master limit command:
:LATChed <b> Enable or disable master limit latch. OFF
:OUTPut Path for limit output commands:
[:STATe] <b> Enable or disable limit outputs. OFF
[:STATe]? Query state of limit outputs.
:PULSe Path to control limit output pulsing:
[:STATe] <b> Enable or disable limit output pulsing. OFF
[:STATe]? Query state of limit output pulsing.
:TIME <NRf> Set output pulse time in sec (0.001 to
99999.999).
0.002
:TIME? Query output pulse time.
:LSENse <name> Set logic sense of all limit lines (AHIGh or
ALOW).
AHIGh
:LSENse? Query logic sense of limit lines.
:LIMit1 Path to control LIMIT 1 test:
:UPPer Path to configure upper limit:
[:DATA] <n>
[, <clist>]
Set upper limit (-4294967295 to
+4294967295).
1
[:DATA]? [<clist>] Query upper limit.
:LOWer Path to configure lower limit:
[:DATA] <n>
[, <clist>]
Set lower limit (-4294967295 to
+4294967295).
-1
[:DATA]? [<clist>] Query lower limit.
:STATe <b>
[, <clist>]
Enable or disable limit test. OFF
:STATe? [<clist>] Query state of limit test.
:FAIL? Query test result (1 = failing).
:CLEAR Path to clear events:
[:IMMediate] Clear high and low events.
:AUTO <b> Enable or disable auto-clear. ON
:AUTO? Query auto-clear.
Table 15-1 (continued)
CALCulate command summary
Command Description
Default
parameter Ref SCPI
