Model 2700 Multimeter/Switch System User’s Manual SCPI Reference Tables 15-5
CALCulate3
:LIMit2 Path to control LIMIT 2 test: ✓
:UPPer Path to configure upper limit: ✓
[:DATA] <n>
[, <clist>]
Set upper limit (-4294967295 to
+4294967295).
2 ✓
[:DATA]? [<clist>] Query upper limit. ✓
:LOWer Path to configure lower limit: ✓
[:DATA] <n>
[, <clist>]
Set lower limit (-4294967295 to
+4294967295).
-2 ✓
[:DATA]? [<clist>] Query lower limit. ✓
:STATe <b>
[, <clist>]
Enable or disable limit test. OFF ✓
:STATe? [<clist>] Query state of limit test. ✓
:FAIL? Query test result (1 = failing). ✓
:CLEAR Path to clear events: ✓
[:IMMediate] Clear high and low events. ✓
:AUTO <b> Enable or disable auto-clear. ON ✓
:AUTO? Query auto-clear. ✓
Notes:
1. The :MMFactor and :MA1Factor commands perform the same operations.
2. The :MBFactor and :MA0Factor commands perform the same operations.
3. For mX+b units, <char> = one character; ‘A’ through ‘Z’, degrees symbol (‘°’), or ohms symbol (‘Ω’).
Table 15-1 (continued)
CALCulate command summary
Command Description
Default
parameter Ref SCPI

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
