15-6 SCPI Reference Tables Model 2700 Multimeter/Switch System User’s Manual
Table 15-2
DISPlay command summary
Command Description
Default
parameter
Ref SCPI
DISPlay (see Note) Sec 1
[:WINDow[1]] ✓
:TEXT Path to control user text messages. ✓
:DATA <a> ASCII message “a” (up to 12 characters). (none) ✓
:DATA? Query text message. ✓
:STATe <b> Enable or disable message mode. OFF ✓
:STATe? Query text message state. ✓
:ENABle <b> Enable or disable the front panel display. ON ✓
:ENABle? Query state of the display. ✓
Note: *RST and SYSTem:PRESet have no effect on commands in this subsystem. The listed defaults are power-on defaults.
Table 15-3
FORMat command summary
Command Description
Default
parameter
Ref SCPI
FORMat Sec 14
[:DATA] <type>
[,<length>]
Select data format (ASCii, SREal or DREal). ASCii
[:DATA]? Query data format. ✓
:ELEMents <item list> Specify data elements (READing, CHANnel,
UNITs, RNUMber, TSTamp, and LIMits).
(see Note) ✓
:ELEMents? Query data elements. ✓
:BORDer <name> Select binary byte order (NORMal or
SWAPped).
SWAPped ✓
:BORDer? Query byte order. ✓
Note: The SYSTem:PRESet and *RST default is READ, UNIT, RNUM, and TST.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
