Keysight Technologies X Series Service Guide

462 Keysight N9010A EXA Service Guide
Replaceable Parts
Hardware
Item Description Keysight Part Number
1 Front Frame
---
a
2 A1A1MP2 Main Keypad Overlay
Option 503, 507, 513, 526
Option 532, 544
N9030-80002
N9030-80011
3 A1A1MP3 Connector Overlay E4410-80109
4 A1A1MP18 Cover Plate N9020-00002
5 A1A1MP9-10 Front Frame Side Trim Strip W1312-40005
6 A1A1MP4 Front Frame Ground Spring W1312-00021
9 A1A2 Front Panel Interface Board N9020-60277
10 A1A2MP1 Speaker 9164-0453
11 A1A2MP2 Speaker Foam W1312-40016
12 A1A3 Liquid Crystal Display 2090-0997
14 A1A5 Front Panel Daughter Board N9020-63193
15 A1MP1 Main Keypad E4410-40100
16 A1MP2 Display Keypad E4410-40101
17 A1MP9 RPG Knob W1312-40017
18 A1MP3 Frequency Label, 3.6 GHz
A1MP4 Frequency Label, 7 GHz
A1MP5 Frequency Label, 13.6 GHz
A1MP6 Frequency Label, 26.5 GHz
A1MP16 Frequency Label, 32 GHz
A1MP17 Frequency Label, 44 GHz
N9010-80008
N9010-80009
N9010-80010
N9010-80011
N9010-80006
N9010-80007
19 A1MP8 LCD Lens Gasket W1312-40006
20 A1MP7 LCD Glass Filter 1000-1513
24 A1A4 DC-DC Converter (LED display backlight power) 0950-5235
25 A1MP24 Magnetic Shield (Display Bracket to Front Panel
Interface/Speaker Bracket)
N9020-00029
26
A1MP23 Front Panel Interface/Speaker Bracket N9020-00028
30 A1MP14 Display Bracket W1312-00145
34 A1W1 Flex Circuit, Display to Front Panel Interface Board W1312-60122
35 A1W3 Power Cable, Front Panel Interface board to DC-DC
Converter
W1312-60130
36 A1W4 Power Cable, DC-DC Converter to Display W1312-60131
a. Non-orderable item, see A1A1.
