588 Keysight N9010A E
XA Service Guide
Assembly Replacement Procedur
es
Fr
ont Frame Assemb
ly
Figure 15-96
Fr
ont Frame Assembly Shie
ld
s - LED
Item
Description
1
A1MP23
Front Panel Interface/Speaker
Bracket
28
Screw M3 X 0.5 (5mm long) (0515-0372)
587
589
