98 Keysight N9010A EXA Service Guide
Instrument Messages
-221 Settings Conflict Errors
-221 Settings conflict; Gated FFT
is not available while Sweep
Type is set to Swept
The gated FFT function is not available if you have selected the
swept type of sweep. You must be in the FFT sweep type.
-221 Settings conflict; Gated LO
is not available while Sweep
Type is set to FFT
The FFT sweep type moves the LO frequency in steps. So the gated
LO function is not available if you have selected FFT sweep.
-221 Settings conflict; Gated
Video is not available while
Sweep Type is set to FFT
The gated video function is not available if you have selected the
FFT sweep type.
-221 Settings conflict; Incorrect
RBW for demod. Change RBW
-221 Settings conflict; Ind I/Q
is not available for this
measurement
The Independent I and Q setting is not available for the current
measurement. Only some measurements (initially, only VXA)
support this setting.
-221 Settings conflict; Invalid
trace number
The subopcode used to specify the trace number is invalid for this
measurement or query
-221 Settings conflict; Knob is
not available to modify this
function
You should select a specific value for this function. So scrolling
through values with the knob is not allowed.
-221 Settings conflict; Log Scale
Type is not available when
Detector Mode is Normal
-221 Settings conflict; Log Scale
Type is not available with
Demod View
The logarithmic x-axis scales are not available when you have the
demod view turned on.
-221 Settings conflict; Log Scale
Type is only available in
swept measurement
Logarithmic scaling can be used when making a swept SA
measurement. It is not available in the SA measurement when you
are using FFT sweeps.
-221 Settings conflict; Log Scale
Type not available when
Segmented Sweep is on
The logarithmic scales are not available while you are using the
segmented sweep capability.
-221 Settings conflict; Log Scale
Type only available when
Frequency Offset = 0 Hz
If you have any amount of frequency offset, then you cannot use
logarithmic scaling for the X axis.
-221 Settings conflict; Marker 1
Trace Update=off turns off
Signal Track
Signal Track not available unless the trace containing Marker 1 is
updating
-221 Settings conflict; Marker
cannot be relative to itself
A marker must be set relative to another marker, not to itself.
-221 Settings conflict; Marker
Count is not available when
Gate on
The marker count function cannot be used while you have gating
turned on.
