Keysight N9010A EXA Service Guide 99
Instrument Messages
-221 Settings Conflict Errors
-221 Settings conflict; Marker
Function is not available
for a Fixed marker
If a Marker is a Fixed type marker, the marker's value does not
change from when it first became fixed. You cannot turn on or
change a Marker Function because there is no ongoing
measurement data to use for the marker function calculation.
-221 Settings conflict; Marker
type must be delta
MkrΔ->Span and MkrΔ->CF require that the selected marker be a
delta marker.
-221 Settings conflict; Marker->
command is not available
with segmented sweep
Most of the “Marker To” commands are not available with
segmented sweep turned on. So you cannot select these
functions.
-221 Settings conflict; Marker->
function is not available in
zero span
Most of the “Marker To” functions are not available if you are in
zero span (span = 0 Hz, or time domain). So you cannot send the
commands for these functions.
-221 Settings conflict; Meas Type
was changed to Examine for
Exp Avg Mode.
Average Mode has been changed to Exponential. Full Meas Type is
not available for Exponential Average Mode therefore Meas Type
has been changed to Examine.
-221 Settings conflict; Meas Type
was changed to Full for
Repeat Avg Mode
Average Mode has been changed to Repeat. Examine Meas Type is
not available for Repeat Average Mode therefore Meas Type has
been changed to Full.
-221 Settings Conflict;
MinPts/RBW limit not met
-221 Settings conflict; Mixer
Type is not available when
in this band
The Mixer Type selection is not available in the K, E, W, F, D, G, Y, J
band because those bands do not allow Preselected Mixing.
-221 Settings conflict; Mkr -> CF
is not available when the
x-axis is time domain
The marker to center frequency functionality does not work when
the x-axis is in the time domain.
-221 Settings conflict; MS gain
is not available in this
Mode
Mobile Station gain correction is not available in some Modes, or in
some measurements (for example, the SA measurement).
-221 Settings conflict; No meas
frequencies are above 3.6
GHz
Optimize Preselector can only be performed on frequencies in high
band i.e. freqs above 3.6 GHz. The current setup does not have
input freqs (IF) in this range so an Optimize Preselector cannot be
performed.
-221 Settings conflict; Normal
detector is not allowed with
X scale is Log
The normal detector cannot be used when the x-axis scale is
logarithmic.
Why not? Are the results weird? Frequency slewed?
-221 Settings conflict; Normalize
is not available when Scale
Type = Lin
Normalize does not support Linear amplitude scale, since the
results are always presented as a dB ratio.
-221 Settings conflict; Normalize
is not available while Demod
View is on
The normalization (correction) function cannot be used if you are
using the Demod View.
