TABLE III: DID PANEL FAULT CODES
(Codes Received From Inverter 1, 2)
EVENT
DESCRIPTION
EVENT
RESTRICTION
DETECTION
INFORMATION
EVENT
NUMBER
Limp
Possible
Lockout
Limit
113/213 (cont.)
:29 C volt hi Adn No power
Phase C volt too high while phase A
down on
:30 C volt lo Aup No power
Phase C volt too low while phase A up
on
:31 C volt hi Bdn No power
Phase C volt too high while phase B
down on
:32 C volt lo Bup No power
Phase C volt too low while phase B up
on
:33 C volt hi Cdn No power
Phase C volt too high while phase C
down on
:34 C volt lo Cup No power
Phase C volt too low while phase C
up on
:35 Aup fault cur No power
Phase A fault current when phase A
up on
:36 Adn fault cur No power
Phase A fault current when phase A
down on
:37 Bup fault cur No power
Phase B fault current when phase B
up on
:38 Bdn fault cur No power
Phase B fault current when phase B
down on
:39 Cup fault cur No power
Phase C fault current when phase C
up on
:40 Cdn fault cur No power
Phase C fault current when phase C
down on
:48 A volt hi off No power Phase A voltage high with all GTOs off
:49 A volt lo off No power Phase A voltage low with all GTOs off
:50 B volt hi off No power Phase B voltage high with all GTOs off
:51 B volt lo off No power Phase B voltage high with all GTOs off
:52 C volt hi off No power Phase C voltage high with all GTOs off
:53 C volt lo off No power Phase C voltage high with all GTOs off
:54 phase short pos No power Possible phase to DC+ short
:55 phase short neg No power Possible phase to DC- short
:60 linkV too hi PTL No power Link volts above PTL
:70 Aph neg I low No power
Phase A negative current low
(unbalance)
:71 Bph neg I low No power
Phase B negative current low
(unbalance)
E02014 3/01 Electrical Propulsion System Components E2-17
