TABLE III: DID PANEL FAULT CODES
(Codes Received From Inverter 1, 2)
EVENT
DESCRIPTION
EVENT
RESTRICTION
DETECTION
INFORMATION
EVENT
NUMBER
Limp
Possible
Lockout
Limit
113/213 (cont.)
:72 Cph neg I low No power
Phase C negative current low
(unbalance)
:73 Aph neg I hi No power
Phase A negative current high
(unbalance)
:74 Bph neg I hi No power
Phase B negative current high
(unbalance)
:75 Cph neg I hi No power
Phase C negative current high
(unbalance)
:76 Aph pos I low No power
Phase A positive current low
(unbalance)
:77 Bph pos I low No power
Phase B positive current low
(unbalance)
:78 Cph pos I low No power
Phase C positive current low
(unbalance)
:79 Aph pos I hi No power
Phase A positive current high
(unbalance)
:80 Bph pos I hi No power
Phase B positive current high
(unbalance)
:81 Cph pos I hi No power
Phase C positive current high
(unbalance)
:82 no current w run No power No current while running
114/214 INVERTER, GENERAL
:22 IA VCO lo No Propel Low frequency on IA channel
:24 IB VCO lo No Propel Low frequency on IB channel
:26 linkV VCO lo No Propel
Low frequency on VCO link filter V
channel
:28 infilV VCO lo No Propel
Low frequency on VCO in filter V
channel
:38 LinkV too lo No Propel Link voltage too negative
:40 infilV too lo No Propel Input filter voltage too positive
:46 DB chop VCO lo No Propel
Low frequency on VCO DB chopper
channel
:48 DB chopV too lo No Propel DB chopper voltage too negative
:50 VA VCO lo No Propel Low frequency on VCO VA channel
:52 VB VCO lo No Propel Low frequency on VCO VB channel
:54 VC VCO lo No Propel Low frequency on VCO VC channel
:56 VA volts too lo No Propel VA voltage too negative
:58 VB volts too lo No Propel VB voltage too negative
:61 VC volts too lo No Propel VC voltage too negative
E2-18 Electrical Propulsion System Components E02014 3/01
