L-Gate User Manual 81 LOYTEC
Version 3.2 LOYTEC electronics GmbH
Figure 60: Create a new device in the drawing.
2. Select Commission Device if the device is already connected to the network.
3. In the Device Template group box select the existing device template of the L-Gate.
Select “L-Gate-900 FT-10”, if the L-Gate is configured to use the FT-10 interface, or
“L-Gate-900 IP-10L”, if the L-Gate is configured to be on the IP channel. For
information on how to configure which port to use, refer to Section 4.2.5 for the Web
UI.
4. Select the channel, which the device is connected to and click Next.
5. The following dialog shown in Figure 61 appears, click Next.
Figure 61: Leave defaults for Location.
6. Check Service Pin as the device identification method as shown in Figure 62 and click
Next.
