Chapter 2 - Specification
2-4
Operation
Information
Output Frequency, Output Current, Output Voltage, Frequency Set Value,
Operating Speed, DC Voltage, Integrating Wattmeter, Fan ON time, Run-time,
Last Trip Time
DISPLAY
Keypad
Trip
Information
Trips Indication when the Protection Function activates. Max. 5 Faults are
saved. Last Trip Time.
Ambient Temperature
-10℃ ~ 40℃ (14℉ ~ 104℉) (Use loads less than 80% at 50℃)
Storage Temperature
-20℃ ~ 65℃ (14℉ ~ 149℉)
Ambient Humidity Less Than 90 % RH Max. (Non-Condensing)
Altitude – Vibration Below 1,000m (3,300ft), Below 5.9m/sec
2
(0.6g)
ENVIRONMENT
Application Site Pollution degree 2, No Corrosive Gas, Combustible Gas, Oil Mist, or Dust
(1) Rated capacity (√3×V×I) is based on 220V for 200V class and 460V for 400V class.
(2) Indicates the maximum applicable capacity when using a 4-Pole standard motor.
(3) IP20 or UL Enclosed Type1 can be provided by the option.
(4) IP20 or UL Enclosed Type1 is not provided.
(5) Overload rating 120%, 1 min is based on ambient 25℃.
(6) MMC(Multi Moter Control) function is applied to the drives only for 5.5 ~ 90kW(7.5 ~125HP).
