Chapter 9 – RS485 Communication
9-9
Address Parameter Unit Unit R/W Data value
BIT 7: DC Braking
BIT 8: Stopping
Bit 9: not Used
BIT10: Brake Open
BIT11: Forward run command
BIT12: Reverse run command
BIT13: REM. R/S (Int. 485, OPT)
0x000E Operating status of Inverter R
BIT14: REM. Freq. (Int. 485, OPT)
BIT 0 : OCT1
BIT 1 : OV
BIT 2 : EXT-A
BIT 3 : BX
BIT 4 : LV
BIT 5 : RESERVE
BIT 6 : GF(Ground Fault)
BIT 6: OHT (Inverter overheat)
BIT 7: ETH (Motor overheat)
BIT 8: OLT (Overload trip)
BIT10: HW-Diag
BIT11: RESERVE
BIT12: OCT2
BIT13: OPT (Option error)
BIT14 : PO (Phase Open)
0x000F Trip information R
BIT15: IOLT
BIT 0 : M1
BIT 1 : M2
BIT 2 : M3
BIT 3 : M4
BIT 4 : M5
BIT 5 : M6
BIT 6 : M7
BIT 7 : M8
BIT 8 : P4
BIT 9 : P5
0x0010 Input terminal status
R
BIT 10 : P6
BIT 0 : AUX1
BIT 1 : AUX2
BIT 2 : AUX3
BIT 3 : AUX4
BIT 4 : Q1 (OC1)
BIT 5 : Q2 (OC2)
BIT 6 : Q3 (OC3)
0x0011 Output terminal status
R
BIT 7 : 30AC
0x0012 V1 0~10V R
0x0013 V2 0~10V R
0x0014 I 0~20mA R
0x0015 RPM R
