Manitowoc Grove GMK4100L-1 - Page 7

Additional pages GMK4100L-1 3 302 710 en 3
16.01.2018
1 Transmission mode RM à p. 8
2 Transmission mode R
à p. 7
3 Neutral position N
à p. 7
4 Transmission mode D
à p. 7
5 Transmission mode DM
à p. 8
6 Current transmission mode display
7 Steering lock display
à p. 6
8 Current wheel position display
à p. 11
9 Change-over between crane operation and driving modes
à p. 6
10 – Transverse differential locks display
– Transverse differential locks on/off
à p. 9
à p. 9
11 – Longitudinal differential lock display
– Longitudinal differential lock on/off
à p. 9
à p. 9
12 Supply pressure brake circuits 1 and 2 display
à p. 10
13 Parking brake indicator lamp
à p. 10
14 Display of crane's hydraulic system driving mode on/off
à p. 6
15 Steering mode switched on indicator
16 Normal steering mode/on-road driving on
à p. 13
17 Separate steering, manual on
à p. 12
18 Automatic separate steering driving around corners on
à p. 13
19 Automatic separate steering for crab travel mode on
à p. 13
20 Changing the steering direction
1)
à p. 12
1)
Display depends on carrier display; à p. 5
