SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-6
Published 08-12-19, Control # 224-13_v2
Shackle #
Part #
A
mm (in)
B
mm (in)
C
mm (in)
D
mm (in)
E
mm (in)
F
mm (in)
G
mm (in)
H
mm (in)
J
mm (in)
K
mm (in)
SH 1 (2)
81007187
325
(12.80)
70 (2.76) 70 (2.76)
254
(10.00)
434
(17.10)
150
(5.90)
70 (2.76)
105
(4.10)
70 (2.76)
185
(7.30)
SH 2 (4)
81024427
174,80
(6.88)
41,10
(1.62)
38,80
(1.53)
167,10
(6.58)
254
(10.00)
92.20
(3.63)
42,50
(1.67)
60 (2.36) 38 (1.50)
98,6
(3.88)
SH 3 (4)
81030038
225 (8.90)
57,30
(2.26)
45 (1.77)
177,80
(7.00)
313,7
(12.40)
106,40
(4.20)
50,80
(2.00)
73,20
(2.90)
45 (1.77)
127
(5.00)
FIGURE 4-7
Item Description
G Basket Hitch
H Choker Hitch
G
H
Sling #
Part #
A
m (ft)
B
mm (in)
C
kg (lb)
D
kg (lb)
E
kg (lb)
F
kg (lb)
G
kg (lb)
H
kg (lb)
SL 1 (2)
81038731
3,30
(10.83)
70,00
(2.75)
45 360
(100,000)
39 281
(86,600)
32 069
(70,700)
22 680
(50,000)
90 718
(200,000)
36 287
(80,000)
SL 2 (2)
81038732
3,10
(10.30)
44,50
(1.75)
18 144
(40,000)
15 712
(34,640)
12 828
(28,280)
9 072
(20,000)
36 287
(80,000)
14 515
(32,000)
SL 3 (1)
81038797
1,60
(5.25)
31,80
(1.25)
9 072
(20,000)
7 856
(17,320)
6414
(14,140)
4 536
(10,000)
18 144
(40,000)
7 257
(16,000)
SL 4 (4)
81040162
3,80
(12.50)
44, 50
(1.75)
11 340
(25,000)
9 820
(21,650)
8017
(17,675)
5 670
(12,500)
22 680
(50,000)
9 072
(20,000)
SL 5 (1)
81040488
2,60
(8.50)
76,20
(3.00)
56 700
(125,000)
49 101
(108,250)
40 086
(88,375)
28 350
(62,500)
113 400
(250,000)
45 360
(100,000)
SL 6 (4)
81042116
5,00
(16.40)
54,00
(2.13)
31 751
(70,000)
27 497
(60,620)
22 448
(49,490)
15 876
(35,000)
63 503
(140,000)
25 401
(56,000)
Shackle
Part #
Shackle Capacities
Metric Ton (US Ton)
SH 1 (2)
81007187
55 t (60.60 USt)
SH 2 (4)
81024427
17 t (18.70 USt)
SH 3 (4)
81030038
40 t (44.00 USt)
