SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-86
Published 08-12-19, Control # 224-13_v2
Item Description
1 Upper Boom Point
2 Lower Point Sheaves
3 Boom Top Assembly
4 Weight Ball
5Block
6 Luffing Jib Wire Rope Guides
7 Insert w/Sheaves
8 Drum 2 Main Hoist (optional)
9 Drum 6 Luffing Hoist (optional)
10 Butt Assembly
11 Drum 0 Rigging Winch
12 Operator Cab
13 Swing Drives
14 Crawlers
15 Upperworks
16 Lowerworks
17 Adapter Frame
18 Rotating Bed Jacking Cylinders (optional)
19 Rotating Bed
20 Counterweight Tray
21 Counterweight Rail
22 Gantry
23 Boom Hoist Wire Rope
24 Live Mast
25 Self-Erect Cylinder
26 Counterweight Boxes
27 Drum Boom/Mast Hoist
28 Drum 3 Whip Hoist
29 Boom Stops
30 Drum 1 Main Hoist
31 Lifting Lug Wire Rope Guide
32 Wire Rope
33 Boom Straps
34 Luffing Jib Cable Guide
35 Wire Rope Guide
FIGURE 4-68
