SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-96
Published 08-12-19, Control # 224-13_v2
Item Description
1 Fixed Horizontal Pin (2 each section)
2 Hooked Connector (2 each section)
3 Safety Pin (2 each section)
4 Hand-held Pin Puller
5a Pin (shipping position)
5b Pin (working position)
6 Insert with sheaves
7Insert
8 Pin with Safety Pins (2 each section)
9 Storage Bracket (2 each section)
FIGURE 4-74
VIEW A
VIEW B
VIEW C
OR
VIEW E
VIEW D
