SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-104
Published 08-12-19, Control # 224-13_v2
FIGURE 4-81
VIEW A
VIEW B
Item Description
1 Wire Rope Guide
2 Pins and Safety Pins
3a Struts (shipping position)
3b Struts (shipping position)
(2)
(2)
