7 Additional settings
Sample input
The sample input can be used for saving the current position in the internal memory so that
it can be used for calculations (e.g. for length measurements or for increasing the
resolution for flying saw applications).
Homing process
For homing, the start signal and the reference switches can be actuated by way of digital
inputs.
The following table provides an overview of the permissible assignments between the
various functions and digital inputs:
Digital input
0 1 2 3 4 5 6 7 8
Function
Position selector bit 0 ● + + + + - - - -
Position selector bit 1 + ● + + + - - - -
Position selector bit 2 + + ● + + - - - -
Position selector bit 3 + + + + + - - - -
Position selector bit 4 + + + + + - - - -
Position selector bit 5 + + + + + - - - -
Position selector bit 6 + + + + + - - - -
Position selector bit 7 + + + + + - - - -
Sample input - - - - - - - - ●
Positioning start - - - - ● - - - +
Controller enable signal - - - - - H - - -
Limit switch 0 - - - - - - H - -
Limit switch 1 - - - - - - - H -
Digital stop + + + + + - - - -
Jog left + + + + + - - - -
Jog right + + + + + - - - -
Start homing + + + + + - - - -
HOME program + + + + + - - - -
START program + + + + + - - - -
NEXT1 program + + + + + - - - -
NEXT2 program + + + + + - - - -
Program stop + + + + + - - - -
Program start/stop + + + + + - - - -
Reference switch - - - - + - - - ●
Set-up mode + + + + + - - - -
Explanation: + permissible, • permissible (default), - not permissible, H hard-wired
Product manual BL 4000-C Page 170 of 298
