7 Additional settings
Digital input Affects See section
Position selector Positioning
process
6.2.8 Jog mode Page 1
Start Positioning
process
6.2 Positioning process Page 86
Sample input Positioning
process
6.4 Flying saw Page 108
Digital stop Speed control
process
5.2.2 Speed-controlled mode (speed
control)
Page 66
Positioning
process
5.2.3 Position-controlled mode and
positioning mode (positioning
process)
Page 67
Start homing Homing
process
6.1 Homing process Page 73
Reference
switch
Homing
process
6.1 Homing process Page 73
HOME program Motion
program
6.2.7.3 Digital inputs - Motion program Page 101
START program Motion
program
6.2.7.3 Digital inputs - Motion program Page 101
NEXT1 program Motion
program
6.2.7.3 Digital inputs - Motion program Page 101
NEXT2 program Motion
program
6.2.7.3 Digital inputs - Motion program Page 101
Program stop Motion
program
6.2.7.3 Digital inputs - Motion program Page 101
Combined
start/stop
Motion
program
6.2.7.3 Digital inputs - Motion program Page 101
(Jogging)
negative
Jog mode 6.2.8 Jog mode Page 102
(Jogging)
positive
Jog mode 6.2.8 Jog mode Page 102
Product manual BL 4000-C Page 171 of 298
