Midas PRO2 User Manual

98 Chapter 11: Panning
PRO2 Live Audio System
Owner’s Manual
SIS™ (LCR) mode
The MIDAS SIS™, which is used for left-centre-right (LCR) loudspeaker systems,
configures the channel for LCR mixing. The SIS switch activates the spatial imaging
system, which uses the SIS image control knob to modify pan control knob operation
so as to place the channel within a three-speaker system.
With SIS image control knob set fully clockwise or anti-clockwise, image is full LCR or
stereo, respectively. Control knob positions in between generate a composite blend of
stereo or LCR panning systems, so that optimum degrees of centre image focus and
speaker power can be obtained.
Constant power is maintained at all times so that the image can be adjusted during the
show without a perceived change in level.
SIS image control knob fully clockwise (LCR)
With the SIS image control knob
fully clockwise, the pan control
knob operates in full LCR mode. A
centre-panned signal, that is, with
the pan control knob set to the c
position, routes to the centre
speaker only; there is no signal in
the left and right speakers.
Left
Centre
Right

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
