Setting up the effects rack 79
PRO2 Live Audio System
Owner’s Manual
Setting up the effects rack
You can set up the effects rack (in the GUI menu’s Effects
screen) to contain any of the eight available effects listed in
the Change Device Type window, in any of the 16 rack
positions. The diagram right shows the rack populated with
all available effects.
The assignable controls (shown in the Delay diagram) are
common to all effects, and let you control effects parameters
via the I zone (output bay’s control surface).
Stereo delay — provides simple
delay line-based effects. Delay
times can be specified manually or
you can use the ‘tempo-tap’ button.
DN780 (stereo reverb) — is a
reverberation device that emulates
the Klark Teknik DN780 Digital
Reverberator/Processor unit and
allows you to create unique acoustic
environments of virtually any type.
Stereo flanger — has one or, if
configured as stereo, two tap delay
lines. One tap is fixed and the other
tap position is modulated to provide
‘thru-zero’ flanging or single tap
modulation when ‘thru-zero’ is off.
Stereo phaser — has one, or if
configured for dual operation, two
stereo phasers connected in serial or
parallel, according to mode setting.
Pitch Shifter (harmoniser) — has
two independent channels that can
independently shift the pitch of
signals up/down to correct poor
pitching or generate harmonies. The
pitch change can also be modulated
as an effect.
8-channel SQ1 Dynamics — is an
emulation of the Klark Teknik
Square ONE Dynamics, which is an
8-channel analogue dynamics
processor. Used for the precise
manipulation of compression
parameters, it also includes gating
for creative and corrective
applications, and channel linking for
stereo/multi-channel operation.
