Midas PRO2

Inputs 339
PRO2 Live Audio System
Owner’s Manual
Inputs
Each scope screen has 56 input channels in the Input Channels section.
Figure 30: Parameter sections per input channel
Patching
The following diagram details the scoped patching parameters of the input channels,
and shows the configuration detail area in the GUI channel strip.
* Includes tape return and primary input sources.
ABC
D E F G H
Item Parameter
1 Input patching source
Yes* Yes*
No N/A N/A N/A N/A N/A
56 input channels
Routing (A)
All (B)
Mic Amp (C)
EQ (D)
Dyn (E)
Busses (F)
Mute (G)
Fader (H)
A
B
C
D
E
F
G
H
1
