64 Chapter 8: Patching
PRO2 Live Audio System
Owner’s Manual
How to patch
Patching, basically, involves selecting the source patching connectors in the From
section of the Patching screen and then selecting their destination(s) in the To section.
You can select patches singly, or in multiples by using the sequence and automatic
operations.
About the patch connectors
Each patch connector has three possible states, as indicated by its fill colour. The
following table shows what each state signifies (the examples show XLR connectors,
although it applies to any type of patch connector).
Working with patch connectors
You can select patch connectors one at a time by clicking on them, or you can select
them in blocks by using a drag operation. All of the patch connectors in both the From
or To sections are on tabs so, before you can select a patch connector, its tab must be
open.
>> To open a tab in the From or To sections
Click the tab title. For example, Ins. Sends (insert sends).
>> To select a single patch connector
Click the patch connector. The effects of clicking a patch connector are shown in the
following table.
Table 2: Effects of clicking a patch connector
Symbol Description
Patch connector is neither selected or patched.
Patch connector is selected, but can be in either a patched or unpatched
condition.
Patch connector is patched, but not selected.
Click To do this in the From section To do this in the To section
Select the patch the connector ( ).
Will do one of the following (provided a
source patch connector(s) has been
selected in the From section):
• Select the patch connector ( )
during a single patching operation.
• Patch the patch connector ( )
during either a sequence or an
automatic patching operation.
Otherwise, this has no effect.
