Midas PRO2 User Manual

Matrices 363
PRO2 Live Audio System
Owner’s Manual
Matrices
Each scope screen has eight matrices in the Matrix section.
Patching
The following diagram details the scoped patching parameters of the matrix channels,
and shows the configuration detail area in the GUI channel strip.
B
D E G H
Item Parameter
1 Output patching No N/A N/A N/A N/A
All (B)
EQ (D)
Dyn (E)
Mute (G)
Fader (H)
B
D
E
G
H
1

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
