146 Chapter 17: Control Groups
PRO2 Live Audio System
Owner’s Manual
POPulation groups
There are six POPulation groups. Although similar to VGA groups in their methods of
group management and selection, they have limited functionality.
POPulation groups on the control surface and GUI
MCA groups
The GUI shows the MCA level associated with the selected mix, as shown in the
lower-right corner of the screen. Selecting a VCA shows the VCA level. For information
on how to use MCAs, see the PRO2 Live Audio System Quick Start Guide.
Item Description
1 LCD select button, selects the VCA group and is also used for group
member assignment.
2 Area B button. When this is enabled, the first three group members are
assigned to area B on group activation.
3 unfold button, assigns the POPulation group to the control surface,
unfolding the group members to the channel faders.
4 POPulation group ID — fixed and user-configured name of group.
