Midas PRO2

PRO2 system inputs and outputs 311
PRO2 Live Audio System
Owner’s Manual
PRO2 system inputs and outputs
DL251 I/O box - analogue inputs
DL251 I/O box - analogue outputs
DL251 I/O box - MIDI
DL251 I/O box - digital system inputs and outputs
PRO2 control surface - DSP/router system inputs and outputs
Connector 3-pin XLR balanced
A/D converter 24-bit, 96kHz and 128 times oversampling
Connector 3-pin XLR balanced
D/A converter 24-bit, 96kHz and 128 times oversampling
MIDI In, Out and Thru on 5-pin DIN
System connector 2 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
N+1 connector 1 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR providing redundant
back-up
System connector 2 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
N+1 connector 1 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR providing redundant
back-up
System expansion connector 3 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
Word clock IN connector BNC
Word clock OUT connector BNC
AES3 sync IN connector 3-pin XLR
AES3 sync OUT connector 3-pin XLR
