Midas PRO2 User Manual

310 Appendix C: Technical Specification
PRO2 Live Audio System
Owner’s Manual
Signal path noise 22Hz to 22kHz unweighted
Inputs 150R terminated.
Dynamic range 22Hz to 22kHz unweighted
Input Output Gain
Output
Noise EIN
DL251 I/O box DL251 I/O box 0dB -85dBu -85dBu
DL251 I/O box DL251 I/O box 45dB -81dBu -126dBu
Surface I/O Surface I/O 0dB -85dBu -85dBu
Surface I/O Surface I/O 45dB -81dBu -126dBu
DL451 I/O box DL451 I/O box 0dB -89dBu -89dBu
DL451 I/O box DL451 I/O box 40dB -87dBu -127dBu
DL431 splitter DL431 A out 0dB -98dBu -98dBu
DL431 splitter DL431 A out 40dB -88dBu -128dBu
DL431 splitter DL431 B out 0dB -98dBu -98dBu
DL431 splitter DL431 B out 40dB -88dBu -128dBu
DL431 splitter DL431 C out -6dB -123dBu -117dBu
DL431 splitter DL451 I/O box 0dB -89dBu -89dBu
DL431 splitter DL451 I/O box 40dB -87dBu -127dBu
Input Output Gain
Maximum
Output
Dynamic
Range
DL251 I/O box DL251 I/O box 0dB +21dBu 106dB
DL251 I/O box DL251 I/O box 45dB +21dBu 103dB
Surface I/O Surface I/O 0dB +21dBu 106dB
Surface I/O Surface I/O 45dB +21dBu 103dB
DL451 I/O box DL451 I/O box 0dB +21dBu 110dB
DL451 I/O box DL451 I/O box 40dB +21dBu 108dB
DL431 splitter DL431 A out 0dB +26dBu 124dB
DL431 splitter DL431 A out 40dB +26dBu 114dB
DL431 splitter DL431 B out 0dB +26dBu 124dB
DL431 splitter DL431 B out 40dB +26dBu 114dB
DL431 splitter DL431 C out -6dB +21dBu 144dB
DL431 splitter DL451 I/O box 0dB +21dBu 110dB
DL431 splitter DL451 I/O box 40dB +21dBu 108dB

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
