Midas PRO2 User Manual

191
PRO2 Live Audio System
Owner’s Manual
Chapter 23: Crossfades (Automation)
This chapter shows you how to use crossfades.
Crossfades are events that are triggered using the standard event mechanism, and are
managed via the Automation screen. A crossfade event is managed in a similar way
to any other event, such as GPIO and MIDI, and is detailed later on in this section.
A crossfade event is a trigger to change the value of a control — most often but not
always a fader — between two levels, that of the current control position and that of the
position in another scene, over time. If the level in the next scene is higher than the
current level, the crossfade uses the 'fade up' time; if it is lower, it uses the 'fade down'
time.
About the crossfade Edit Event window
You can edit the parameters of a crossfade event in the Edit Event window.
Crossfade Edit Event window (for details of the Edit Event window elements that are
common to each event type, see Figure 25 “Edit Event window” on page 222)
Item Element Description
1 Crossfade Group
Edit button
Opens the Crossfade Groups screen (see
“Crossfade groups” on page 195).
2 Crossfade set up
section
See “Crossfade set up section in the Edit Event
window” on page 193.
Parameter drop-down list
The Incoming and Outgoing options
are not used on crossfades
1
4
3
2

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
