Midas PRO2 User Manual

192 Chapter 23: Crossfades (Automation)
PRO2 Live Audio System
Owner’s Manual
About the crossfade parameters
The following diagram shows the PRO2 configured for 5.1 surround mode, which utilises
each available parameter option. The presence of the divergence, centre level and
LFE level sections are dependent on the currently selected surround mode.
3 Parameter drop-
down list
For choosing the level control that you want the
crossfade to operate on (see “About the crossfade
parameters” on page 192).
4 Crossfade Group
drop-down list
Contains all of the available user-configured
crossfade groups. Also includes the default example
group that contains all possible crossfade sources.
Item Element Description
image/front
back
Pan
Front Div
F-R div
Centre
Sub
Mute
Fader
Mute
Fader
Rear Div

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
