Midas PRO2 User Manual

Inputs and output characteristics 313
PRO2 Live Audio System
Owner’s Manual
PRO2 control centre - miscellaneous inputs and outputs
Inputs and output characteristics
Analogue input characteristics
Analogue output characteristics
Digital I/O characteristics
Monitor output connector 3-row, 15-pin D-type - analogue VGA
USB host connection USB 2.0 full speed (12.0Mbs)
5V, 1A maximum load
Lamp connector 3-pin XLR
Input Type Load Z Gain Maximum Level Connector
DL251 I/O box 10k -22.5dB to +65dB +24dBu XLR
Surface I/O 10k -22.5dB to +65dB +24dBu XLR
DL451 I/O box 10k -25dB to +60dB +26dBu XLR
DL431 splitter 5k -22.5dB to +65dB +24dBu XLR
Talk mic 600R +15dB to +60dB +6dB XLR
Monitor 10k 0dB +24dBu XLR
Output Type Source Z Gain
Maximum
Level Connector
DL251 I/O box 50R 0dB +21dBu XLR
Surface I/O 50R 0dB +21dBu XLR
DL451 I/O box 50R 0dB +21dBu XLR
DL431 splitter (main) 150R 0dB +24dBu XLR
DL431 splitter (isolated) 75R -6dB +18dBu XLR
Talk 50R 0dB +24dBu XLR
Monitor 50R 0dB +24dBu XLR
Headphones 10R +10dB 750mW 1/4” Jack
Type Channels Data Length I/O
Description
Notes Connector
AES3 2 24-bit Input Conforms to
AES3-2003
XLR
AES3 2 24-bit Output Conforms to
AES3-2003
XLR
AES50 24 24-bit Bi-directional Conforms to
AES50-2006
EtherCon®
XLR

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
