40 Chapter 6: Working With The PRO2 Control Centre
PRO2 Live Audio System
Owner’s Manual
Parameter values displayed on touch
You can configure the PRO2 (see “Setting the user interface
preferences” on page 209) so that the GUI displays the current
value (and dimension) of the control being adjusted.
If you adjust an aux via the mixes section of an input fast strip,
the current value will be shown in the aux’s panel of the GUI input
fast strip.
Operating the GUI screen controls
This section shows you how to operate GUI screen elements, such as buttons, control
knobs, drop-down lists and sliders.
>> To switch a GUI button on/off
Click the button. If it has a status indicator, this will illuminate/extinguish to show that
it is on/off, respectively.
>> To adjust a GUI control knob or fader
Use a drag operation. Move the pointer up/down/left/right for adjustment.
Using drop-down lists
Certain configurable name fields, particularly the signal routing ones, have drop-down
lists that offer a number of preset or context-sensitive options to choose from. Long
lists — containing more options than can be displayed simultaneously — have sliders
that allow you to access all of the options.
>> To select an option from a drop-down list
1 Click the drop-down arrow. The drop-down list
will unfold to display some or all of its contents,
depending on how many items it contains.
2 Do one of the following:
• Click the option you require.
• If necessary, scroll the list (see “To scroll a
drop-down list” below) to display the option, and then click it.
