Midas PRO2 User Manual

154 Chapter 19: Assignable Controls
PRO2 Live Audio System
Owner’s Manual
Operating the channel fader assignments
During normal operation the assignments of the assignable controls section follow
the cross-hair (see “GUI cross-hair” on page 39) detail area selection. This lets you
control a predetermined button and control knob within the selected detail area.
Although you can change the button assignment within a detail area (using the ALT
button) the control knob assignment remains fixed.
Diagram showing the detail area control assignments of the assignment controls
Yellow border around a
detail area indicates that
is the one currently
selected across all
channels
Yellow border around a
button indicates that is the
one currently assigned to
the associated button in
the assignable controls
section
GUI screen
Each set of assignable controls operates the selected detail area
controls of the channel currently assigned to the channel fader strip
immediately below
ALT button changes the button
assignment within a detail area
In this example, pressing
this assignable control
button will operate the ON
button of the channel gate

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
