Midas PRO2 User Manual

314 Appendix C: Technical Specification
PRO2 Live Audio System
Owner’s Manual
Miscellaneous digital characteristics
Main processing functions
Main input channel functions
Type I/O Description Notes Connector
Word clock IN Accepts TTL level, 96kHz square wave;
impedance 75 ohms
BNC
Word clock OUT Provides TTL level, 96kHz square wave BNC
AES sync IN Accepts a 96kHz digital audio signal
conforming to AES3-2003
XLR
AES sync OUT Provides a 96kHz grade II reference
signal conforming to AES3-2003
XLR
Input channel hi pass 10Hz to 400Hz swept in digital domain
Slope selectable 12dB/Oct or 24dB/Oct
Input channel lo pass 2kHz to 20kHz swept in digital domain
Slope selectable 6dB/Oct or 12dB/Oct
Input channel treble Parametric Operation
Frequency 1kHz to 25kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Shelf Operation
Frequency 1kHz to 25kHz swept
Gain +16dB to –16dB
Soft, Classic or Bright (minimum harmonic disruption) curves
Input channel hi mid Parametric Operation
Frequency 320Hz to 8kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Input channel lo mid Parametric Operation
Frequency 80Hz to 2kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Input channel bass Parametric Operation
Frequency 16Hz to 400Hz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Shelf Operation
Frequency 16Hz to 400Hz swept
Gain +16dB to –16dB
Warm, Classic or Deep (minimum harmonic disruption) curves

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
