Controlling a rotary control 155
PRO2 Live Audio System
Owner’s Manual
Controlling a rotary control
An important function of the PRO2 is one that lets you operate any of the control knob
functions on the control surface, such as gain trim, compressor/gate threshold and
level, and even any of the internal effects (but not the GEQs), from the assignable
controls section. This gives you quick access to the controls that are currently the
most useful to you. The Assignable Controls window lets you assign your desired
controls and also shows you the current assignments and status of each one.
In addition, you can assign the ‘tap’ function of the Delay effect to any pushbutton in
the assignable controls section. This function — which is also available via the
tap L/tap R parameters when operating the Delay effect from here — lets you input the
delay time manually by tapping the pushbutton instead of choosing a value (see “To
manually set the tap time of an effect” on page 156).
Assignable Controls window
Item Element Function
1 Name field Channel name, with background colour to match the
default/user-defined channel colour.
2 Control knobs User-assigned controls.
3 Button Collapses the control selection lists (item 5).
4 Button Assign/unassign button.
5 Control selection
lists
These offer you all the available options from which to
choose your rotary control assignment.
6 Option list Available control options for the selected
channel/effect.
7 Option list Available channels/effects for the selected channel
type/effect.
8 Option list Available channel types/effect. The options are:
Unassigned; Inputs; Aux Sends; Matrix; Aux
Returns; Masters; and Effects.
