Midas PRO2 User Manual

Input metering 241
PRO2 Live Audio System
Owner’s Manual
Input metering
The Console Overview screen shows all of the meters all of the time. Meters can be
switched globally to monitor the raw A/D input point, and are also individually
switchable using the meter CHECK button in the gain section (see “Mic amp input gain
(preliminary input processing)” on page 244).
Item Description
1 11-segment meter for showing the input channel level
2 SOLO switch for switching the input channel’s solo on/off
3 MUTE switch for muting the input channel
4 LED meter for showing the gain reduction when using a compressor
5 LED meter for showing the gain reduction when using a gate
6 Input channel fader
7 PRE switch, which is a global meter switch that switches all inputs to
monitor the raw A/D input point.
8 FLIP switch for enabling flip mode.
Channel meters
3
2
1
4
5
1
3
2
6
6
7 8

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
