Midas PRO2 User Manual

GEQs 541
PRO2 Live Audio System
Owner’s Manual
GEQs
You can copy the control settings of any of the GEQs through scenes. Only the Recall
Scope and Store Scope options in the Sections area of the Show Editor screen are
applicable to this option.
Effects
With only the internal effects unit(s) selected, the unit type and control settings of the
desired effect(s) are copied through scenes. In addition, if the Routing option
(Sections area of the Show Editor screen) is selected, the input patching is also
copied through scenes.
Item Control Parameter
1 31 faders Fader positions
2 High pass filter control
knob
High pass filter cut off frequency
3 IN switch High pass filter in/out
4 Low pass filter control
knob
Low pass filter cut off frequency
5 IN switch Low pass filter in/out
6 EQ switch EQ in/out
7 SLOPE switch Low pass filter: 6dB or 12dB
8 Q switch Q mode as proportional (PROP.) or constant
(CON.)
9 IN switch 200Hz - 20kHz notch filter in/out
10 Notch filter control
knob
200Hz - 20kHz notch filter frequency
11 IN switch 20Hz - 2kHz notch filter in/out
12 Notch filter control
knob
20Hz - 2kHz notch filter frequency
13 SLOPE switch High pass filter: 6dB or 12dB
2
3
1
4
5
6
7
89
1011
1213

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
