Midas PRO2 User Manual

EQ (E zone) 257
PRO2 Live Audio System
Owner’s Manual
EQ (E zone)
The input channel equaliser (EQ) is a four-band swept parametric EQ (PEQ) that allows
tonal control of the input signal via the parametric EQ section, or E zone, in the input
channel strip. The four bands are treble, hi-mid, lo-mid and bass, with an additional
three shelving modes available for treble and bass. Any combination of the four bands
can be used to control the signal, although only one band can be adjusted in the E zone
at any time.
The E zone contains all of the PEQ controls, along with a shelving mode selection button
and a set of band selection buttons.
4 Insert return field shows you the source of the insert return.
5 Insert send field has a drop-down list, which shows the destination(s) of the
insert return.
Item Description
2
3
4
5
5
4
6
7
E zone
4
4
1
8
3
6
12
3
Treble and bass
shelving modes
3
3
9
10
2
7
11

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
