Midas PRO2 User Manual

138 Chapter 16: Internal Effects
PRO2 Live Audio System
Owner’s Manual
Feedback
The pitch shifter accepts the input signal and then delays it and plays it back at a
different speed, so that its output is delayed and pitch shifted. When this output is fed
back into the pitch shifter, further delays and more pitch shifting occur. This can lead
to some strange effects, such as feedback.
SQ1 Dynamics effect
For information on the Klark Teknik Square One Dynamics, refer to its Operator Manual
(part number DOC02-SQ1DYNAMIC).
Front panel of the SQ1 dynamics effect
15 ON switch Switches pitch shifter effect on/off.
16 Win Sz control
knob
Sets the window size used by the pitch shift
algorithm. High values result in larger latency, but
better quality for low frequency or polyphonic audio
source. Low values produce low latency and work
best on monophonic audio source.
Item Control Function

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
