Midas PRO2 User Manual

278 Chapter 31: Output Channels
PRO2 Live Audio System
Owner’s Manual
Mute, safes, level and solo
Each output fast strip (control surface and GUI) has controls for muting, soloing, safes
and output signal level control. This is supported on the GUI in the appropriate
processing area. They also each have a SELECT button for navigation. In addition, the
channel strips (control surface and GUI) have the full complement of safes.
Item Description
1 MUTE switch, mutes all post-processing signals leaving the channel. (In
addition to scene recall, muting can be remote from the auto-mute
masters.)
2 Safe LEDs, illuminate when their associated safe is on.
3 SOLO switch, activates signal routing to the monitor A section of the
control centre.
GUI fast strip
1
Masters processing
area in the GUI
channel strip
GUI output fast strip
GUI output fast strip
Mix channel strip
GUI output fast strip
1
1
1
22
2
7
8
3
3
7
8
3
3
7
45
4
5
6
6

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
